MasterCo MB Series Slim Recessed Type LED Round Panel Light
Application: General lighting in corridors / Retail stores / Reception areas / Indoor circulation areas
Brand: MasterCo
Model: MB Series
Shape: Round
Type: Slim Recessed LED Panel Light
Frame Color: White
Material: Aluminum die cast
Choice of color temperature: 3000K / 4000K / 6500K / 3 Color
Light Source: LED
LED Driver: Yes
Input Voltage: AC220-240V~
Input frequency: 50/60Hz
Input Connection: 2 Core – Live and neutral (NO earth required)
Power consumption tolerance: +/-10%
IP Rate: IP20 (Non-Weatherproof, no protection against water, this product should only be installed indoors.)
Dimmable: NO
Product measurement:
Model: | H: | W: | Ceiling cut out: |
MB-RD-3W | 19MM | 3.3" | 2.8" |
MB-RD-6W | 19MM | 4.7" | 4.2" |
MB-RD-9W | 19MM | 5.8" | 5.2" |
MB-RD-12W | 19MM | 6.6" | 6.1" |
MB-RD-15W | 19MM | 7.4" | 6.9" |
MB-RD-18W | 19MM | 8.7" | 8" |
* Specifications & measurements shown are subject to 5% variation.
